Bimetallic Injection Barrels

Barrelize Injection Barrel is are produced to the highest quality standards

*Material: High quality 38CrMoAlA 42CrMo

*Treatment: Nitriding,Bimetallic,Electroplating

*Diameter : Can be customized Φ20mm~ Φ300mm

*Suitable for plastic: PP,PE,ABS,AS,PS,PC,PET ect

*Benefit: Improved product quality,minimize wear,boost output

What is Bimetallic injection barrel?

Barrelize Bimetallic injection barrels are made of two alloy metals. The first metal is the base material and the second metal is the coating material. So the bimetallic injection barrels have better corrosion and abrasion resistance, more durable, and last longer than non-bimetallic ones.

How to make bimetallic injection barrels with two metals ?

Barrelize use an advanced gas furnace to centrifugally cast the lining alloy on the inner surface of the barrel, which greatly provides high surfacing bonding strength, and improves the resistance of the bimetallic injection screw.

What's the specification of Barrelize Bimetallic injection barrell ?

For the first base material, you can choose 38CrMoALA and 42CrMo. For the second metal, Barrelize can offer you iron-based alloy, nickel-based alloy, tungsten carbided alloy. Barrelize can make the thickness of the bimetallic layer : 1.5-2mm. The hardness of an iron-based bimetallic injection barrel can reach HRC60.

The general advantage of Barrelize bimetallic injection barrel: corrosion resistance and wear resistance, improve the strength resistance to fatigue, and finally improve the lifetime.

What is the application for Barrelize Bimetallic injection barrel?

Additive plastic materials with less than 30% glass fiber, corrosion formula, regrinding resin, calcium powder filling, additive fireproof materials, nylon, PVC, PC, PPA, PPO, PPS, PA6T, LCP, ABS, bakelite, fire PC+ glass fiber, Nylon + glass fiber.

Call us now to talk to our team about your specific demand. We have an expert here to listen to your demands and understand what you are looking for.

Product	Material Base	Treatment	Technical Parameter	Application
Barrel	38CrMoAlA	Nitriding	tempering hardness :HB260-280 nitriding hardness: HV950 nitride layer depth :0.4-0.6MM, brittleness:≤ 2	Commonly used for acid-free plastics with GF less than 10%, such as PP\PS＼AS\ABS\TPU\TPE
Barrel	38CrMoAlA	Bimetallic Fe-based alloy	Alloy thickness: 1.5-2MM Surface hardness:HRC60-65	Commonly used for adding acid plastic with GF less than 30%,PC/PA
Barrel	38CrMoAlA	Bimetallic Ni-based alloy+15% tungsten carbide powder	Alloy thickness: l.5-2MM, Surface hardness HRC52~55	Commonly used for adding acid plastic with GF less than 35%, PA/LCP/PBT
Barrel	38CrMoAlA	Bimetallic Ni-based alloy+25% tungsten carbide powder	Alloy thickness: l.5-2MM Surface hardness: HRC58~62	generally used to add aci lastic PEEK/PPS/LCP/flame retardant

Sourcing Plasticizing Equipment Direct from Barrelize

Maximize profits with innovative melt stream components that increase productivity, improve product quality, and prolong lifespan. We are Bimetallic Injection Barrels suppliers, manufacturers. We have our advanced factory. Barrelize stands for pioneering technologies and high quality components and systems for the plastics processing industry in China. Large Stock of our raw material available from our factory. More than only producing screws and barrels for our customers, we remain at any time a problem solver for process improvement. ODM/OEM Bimetallic Injection Barrels Service & Cooperative
